PRODUCT OVERVIEW

Product Overview

Combined tape and covering film

DCRYSTA Pre-Taped Masking Film joins a washi tape edge to an HDPE covering film. The listed film thickness is 8 microns. The product is intended for covering windows and adjacent body panels during paint preparation.

Width, roll length and dispenser

The packing table lists several covering widths, roll lengths and dispenser options. Select the format according to the area and masking method. Secure the film as needed to prevent movement during spraying.

Check the actual tape rating

The product family is described with an 80–120°C high-temperature washi tape option; the specific temperature limit must be confirmed for the tape variant delivered. Do not assume every assembly is approved for a 120°C bake.

Packing

Tape Size Size Width Size Length Dispenser Roll/Carton Core Size Carton Size(cm)
16 mm 55 cm 25 m - 1 roll/shrink wrapped, 60 rolls Ø20.6 mm 38 32
16 mm 110 cm 25 m - 1 roll/shrink wrapped, 30 rolls Ø20.6 mm 38 32
16 mm 140 cm 25 m - 1 roll/shrink wrapped, 30rolls Ø20.6 mm 38 32
16 mm 55 cm 20 m - 1 roll/shrink wrapped, 60 rolls Ø20.6 mm 36 30
16 mm 110 cm 20 m - 1 roll/shrink wrapped, 30 rolls Ø20.6 mm 36 30
16 mm 140 cm 20 m - 1 roll/shrink wrapped, 30rolls Ø20.6 mm 38 32
18 mm 180 cm 33 m - 1 roll/shrink wrapped, 25 rolls Ø20.6 mm 38 38
18 mm 270 cm 33 m - 1 roll/shrink wrapped, 25 rolls Ø20.6 mm 38 38
18 mm 180 cm 33 m √ 1 roll/shrink wrapped, 25 rolls Ø20.6 mm 44 44
18 mm 270 cm 33 m √ 1 roll/shrink wrapped, 25 rolls Ø20.6 mm 44 44
